15
MATERIALS AND TOOLS
Materials
The GS15
plus
uses the same plotting materials as all Gerber plotters.
Gerber vinyl products in high performance or intermediate grades are
available in translucent, reflective, or metallic finishes and come in a
wide range of colors. Also available are direct-cut screenprint stencil,
ruby photo film, paint masking material, rubber sandblast stencil
material and heat transfer materials. Consult your Gerber distributor for
further information about available materials, colors and prices. Always
insist on Gerber authorized materials for highest quality results.
To load material
CAUTION: it is recommended that you load material without a
tool in the carriage to prevent damaging the knife blade.
1. Slide the roll of material to be used onto the roll holder. Pull the end
of the material away from and over the top of the roll holder toward
the plotter.
CAUTION: when power is on, the carriage spindle must be moved
only by using the slew keys. attempts to manually move the
plotter drum, rotate or force the tool up or down will damage
the plotter.
CAUTION: While power is off, center the carriage by gently
pushing toward the center of its travel. Take care to move the
carriage slowly and firmly by gripping the right end of the
carriage housing, not by gripping the carriage spindle.
CAUTION: Do not use the way shafts to lift or turn the GS15
plus
.
This will damage the system and reduce plotting accuracy.
