56 GS15
plus
Troubleshooting Guide
This chart of Z Axis (Tool Height) Adjustment symptoms is designed to
help identify the possible problem and the probable adjustment
procedure.
CAUTION: Turn off GS15
plus
plotter and GRAPHIX
ADVANTAGE or other sign design system before checking
connections or attempting to make any adjustments, unless
otherwise directed.
Symptom Recommended Procedure
No power
1. Check power cable and plugs.
2. Check on/off switches.
3. Check fuse.
Poor Performance Perform routine cleaning and lubrication.
Plotter Error Press Reset on the plotter. Verify and resend the job.
Inconsistent Tool/
Material Contact
1. Clean spindle bore and tool holder.
2. Change knife blade.
3. Check for proper Z home.
4. Perform Z Axis Adjustment for Tool Height.
Jagged or Serrated
Cutting Edges
1. Replace the knife blade.
2. Check for proper theta home. If improper, do theta
adjustment
Closure Problem Check in this order:
1. Material alignment in sprockets
2. Blade position in knife holder.
If the condition still occurs in NORMAL mode (see
GRAPHIX ADVANTAGE Reference), make adjustments in
this order:
Y Axis Backlash Adjustment.
Drum End Play Adjustment.
If the condition occurs when AXIS SWAP in the GRAPHIX
ADVANTAGE is on, perform the X Axis Adjustment.
