48 GS15
plus
ERROR CODES
The error code numbers and suggested operator responses are listed
below. Error code numbers are also listed on the User Reference Card.
Error
Number
Description
Operator Response
1 Program checksum failure Try power-up again.
2 RAM memory failure Try power-up again.
3 RS-232 test failure Try power-up again.
4 Illegal plot data command Check plot data; resubmit
job.
5 Corrupt data Check plot data; resubmit
job.
6 Buffer overflow Contact Gerber Field
Service.
7 UART error Only occurs as part of
self-test; try power-up
again.
8 *Z axes lock time-out Power-up again, holding
RESET key
9 Z axis error Turn off system; check
connectors.
10 Theta home failure Turn off system; check
connectors
*Error code occurs in Special Diagnostic mode, if axes remain locked more than 30 minutes.
If the plotter consistently fails the self-check tests, contact Gerber Field Service Department at 800-
828-5406, or fax at 203-645-2448.
