44 GS15
plus
SQUARE/CIRCLE TEST PLOT
To plot the Square/Circle test plot
1. To access the Square/Circle test plot, hold the RESET key while
powering up.
2. Load vinyl and install the knife holder.
3. Press SLOW key to access diagnostic.
4. Press RUN SINGLE to plot once or RUN CONT to plot
continuously.
5. Compare the test plot to the illustration below. If the plot is
different, contact Gerber Field Service.
