38 GS15
plus
Single Plot Exercise
1. Turn on the GS15
plus
. Load plotting paper, test the pen manually,
install the pen holder, and set the tool force to .5.
2. Using the slew keys, position the carriage spindle approximately 1"
from the front edge of the plotting paper. Also, be sure that there are
several inches of paper extending past the carriage spindle and to the
left of the plotter.
3. Send a plot file to the GS15
plus
plotter.
4. Press the RUN SINGLE key to plot the test exercise.
RUN CONT
Use RUN CONT to access the continuous plotting mode and maximize
the plotter's productivity.
To plot in continuous mode
1. Select either swivel or tangential knife mode by pressing the
SWIVEL KNIFE key. When swivel knife mode is selected, the light
above the SWIVEL KNIFE key is on.
2. Press RUN CONT. The light above the RUN CONT key comes on
and the GS15
plus
plots one job after the other without waiting for
user prompting between the jobs.
3. The GS15
plus
creates a waiting list, or queue, of jobs to be plotted.
When one job finishes plotting, the next job waiting in the queue
begins immediately.
4. When all jobs in the queue are plotted, the GS15
plus
remains on-line
until the operator presses either RUN key or the RESET key to
return to off-line status.
RUN
CONT
