10 GS15
plus
CAUTION: When the power is on, never try to manually move
the carriage, move the drum, rotate the tool, or force the tool up
or down. Attempting to manually move the GS15
plus
in any axis
of movement while the power is on may damage the plotter.
Power-Up Sequence
When the GS15
plus
is turned on, the following sequence occurs:
1. A short beep sounds, the Power light comes on, and the RUN
CONT, RUN SING, and SWIVEL KNIFE lights blink.
2. As the GS15
plus
performs self-check tests, the lights over the RUN
and SWIVEL KNIFE keys flash, and one additional beep sounds.
3. When the self-check is complete, the lights blink and a beep sounds.
4. The plotter goes off-line in tangential knife mode. Only the Power
light remains on. This is the initial setting at power-up.
Note: Rapid, continuous beeping and flashing lights may signal a self-
check error. See the "Error Conditions" section for more information.
