Operation 37
RUN SINGLE
Plot
Use RUN SINGLE to plot a single job. This plot mode allows the
operator to reposition material between jobs and/or to pen plot using
paper before cutting vinyl. RUN SINGLE may be used with either
swivel knife mode or tangential knife mode.
1. Press SWIVEL KNIFE to select a knife mode. (For swivel knife
mode, the light over the SWIVEL KNIFE key is on. For tangential
knife mode, the light is off.
2. Press RUN SINGLE. The light over the RUN SINGLE key comes
on and the GS15
plus
plots a single job. If other plot files are
received from the GRAPHIX ADVANTAGE while the first job
plots, then a waiting list, or queue, of these jobs is created.
3. The GS15
plus
returns to the off-line status after the job plots. It
remains in the knife mode selected.
4. The GS15
plus
waits for the operator to press the RUN SINGLE key
again to plot the next job. If other jobs are lined up in the queue, the
green lights above the two RUN keys will flash.
Controlled Stop
Use RUN SINGLE (or RUN CONT) to pause plotting and check the
current job.
1. Press the currently selected RUN key during a job to pause the job.
The GS15
plus
stops the job at the next logical break in the program.
Note: Do not use slew keys or orientation for the current job will be
lost.
2. Press either RUN key to resume plotting at the exact same point.
RUN
SINGLE
