| CARDIOHELP System | 8 Error Diagnosis | 135 |
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
Self-test:
Warning buzzer 2 does not generate an
alarm
Warning buzzer 2 defective
Replace the sensor panel (kit) (⇨ "Replac-
ing the Sensor Panel (Set)", page 111).
Self-test:
Speaker does not generate an alarm
Volume setting too quiet Check the volume settings, see Instruc-
tions for Use “Changing Brightness/Vol-
ume”
Speaker defective Contact MCP-HTSC.
PC-aided function test
Alarm chain not passed
Program error or transmission error Contact MCP-HTSC.
PC-aided function test
LEDs and/or buttons do not function
LEDs and/or buttons are defective Contact MCP-HTSC.
Program error or transmission error Contact MCP-HTSC.
PC-aided function test
Rotary knob is non-functional
Rotary encoder is defective Contact MCP-HTSC.
Program error or transmission error Contact MCP-HTSC.
PC-aided function test
Night mode
Program error or transmission error Contact MCP-HTSC.
USB data exchange is not possible. USB stick is not plugged in. Insert the USB stick.
USB stick not formatted with FAT/
FAT32.
Use the USB stick recommended by MA-
QUET.
USB stick has insufficient storage
capacity.
Use a different USB stick or delete the
data.
Speed is not at 0 RPM. Turn the speed to 0 RPM.
CARDIOHELP does not have a valid
CARDIOHELP-i license
Inform the customer that a CARDIOHELP-
i license is required for this.
USB data exchange fails (Internal
USB interface is defective).
Switch the CARDIOHELP off and on. Try
the data exchange once more.
Contact MCP-HTSC.
USB stick is not compatible. Use the USB stick recommended by MA-
QUET.
Data exchange via the Ethernet interface
is not possible.
Ethernet connection is nonfunctional. -
Data exchange via the ECG interface is
not possible.
ECG connection is nonfunctional. -
The message no batteries available is dis-
played although batteries are inserted.
Connection between the battery PCB
and the sensor PCB is defective.
Sensor PCB defective.
Battery PCB defective.
Check the connection between the battery
PCB and the sensor PCB.
Check the sensor PCB.
Check the battery PCB.
Contact MCP-HTSC.
Zero flow mode cannot be activated. “Zero flow mode“ button defective The controls foil must be exchanged. Con-
tact MCP-HTSC.
No or insufficient blood flow Inconsistent software versions
Check the software versions (⇨ "Validate
the Software", page 80).
