| CARDIOHELP System | 9 Diagrams | 137 |
Service Manual | 3.3 | EN | 05
Copyright Maquet Cardiopulmonary GmbH
9.1.2 Sensor PCB
Sensor PCB (back side)
X9 ECG Signal
X10 Battery data (from battery PCB)
X11 Cooler housing fan bottom
X13 Battery power (from battery PCB)
X14 Cooler housing fan top
X15 Drive fan 1+2
X16 Power supply (from HMI PCB)
X17 Connection HMI PCB
X18 --
X19 Optional fan
