2.11.20 Bubble Sensor
Bubble sensor
Type
n BS 3/8“ x 3/32“ L.1.7
n BS 3/8“ x 1/16 - 1/4“ x 3/32“ L.1.7
Main function
n Bubble detection
Specification
Voltages
Input voltage 9 V DC
2.11.21 Venous Probe
Venous probe
Type
Venous Probe
Main function
n Measurement of blood parameters
– S
V
O
2
– Hb
– Hct
– T
Ven
Specification
Voltages
Input voltage 9 V DC
