6.18 Replacing Female Connectors Spark plug wrench 11 mm with a torque of 1.3 Nm (for ECG
connector)
Spark plug wrench 14 mm with a torque of 2.5 Nm (for CAN
connector)
Spark plug wrench 17 mm with a torque of 4 Nm (for DC
connector)
Spark plug wrench 22 mm with a torque of 4 Nm (for
emergency mode button)
All hex drive adapters have a 1/4 inch hex drive connection
6.19 Replacing Equipotential Bonding Pin 6. Connect all grounding wires and secure them a hex nut
SW 10 with a torque of 3 Nm. Do not use Loctite!
6.20 Replacing AC Connector Plug 10. Attach the AC connector plug with a torque of 0.5 Nm
and Loctite 270.
Changes throughout Service Manual MPower to Getinge Extranet
Correction of orthographic mistakes
Removed terms "torx" and "allen"
