GIRBAU PB32 Series User Manual

Maintenance 140
Code no. 550038
Rev. no. 16/1018
Steps for cleaning the input photocells (fig.13.3).
The number of linen flow control devices will vary depending
on the model of ironer.
 Clean the linen input tray photocells.
 Turn off the isolator switch controlling the power supply to
the machine.
Fig. 13.3
13.4. Steps for cleaning the air pressure switch circuit pipe
CAUTION
Never perform this operation without having disconnected the power supply.
Before performing this procedure, make sure the temperature of the machine does not present any risk for
handling.
 Turn off the isolator switch controlling the power supply to the machine.
 Disconnect the pipes A and B from the air pressure switch circuit (Fig.13.4).
 Disconnect the pipes A, B and C from the air pressure switch circuit (Fig.13.4).
Fig. 13.4
