GIRBAU PB32 Series User Manual

Technical data 50
Code no. 550038
Rev. no. 16/1018
4.8. Exhaust ducting. Technical and connection details
HEATING
UNITS
PB32
X13
PB/PBP51
X20
G
Maximum
pressure
mmH
2
O
(in.wc)
8.4
(0.34)
17.2
(0.69)
Minimum
flow
m
3
/h
(cu.ft/min)
658
(387)
958
(564)
Maximum
flow
m
3
/h
(cu.ft/min)
1000
(558)
1430
(841)
Diameter
mm
(in)
114
(4.49)
130
(5.1)
E
Maximum
pressure
mmH
2
O
(in.wc)
8.3
(0.33)
18.3
(0.73)
Minimum
flow
m
3
/h
(cu.ft/min)
600
(353)
1077
(634)
Maximum
flow
m
3
/h
(cu.ft/min)
1000
(558)
1430
(841)
Diameter
mm
(in)
114
(4.49)
130
(5.1)
V
Maximum
pressure
mmH
2
O
(in.wc)
- - - - -
18.3
(0.73)
Minimum
flow
m
3
/h
(cu.ft/min)
- - - - -
1077
(634)
Maximum
flow
m
3
/h
(cu.ft/min)
- - - - -
1430
(841)
Diameter
mm
(in)
- - - - -
130
(5.1)
Note. This information should be supplemented with images and information from Section 4.8.
Measurement of maximum pressure (Figure 4.1)
Conditions:
 Maximum pressure measured in the extraction duct, once
the machine is connected to this duct.
 Measuring point: indicated as B in the figure.
 H level value: 500mm (20 in).
 Measurement made at room temperature.
Fig. 4.1
