GIRBAU PB32 Series User Manual

Reception, storage and transport 24
Code no. 550038
Rev. no. 16/1018
2.3.2. Transport of machines without packaging
Before moving the machine, make sure the items to be
used are suitable and capable of bearing its weight. The
weight of the machine and the position of centre of
gravity indicated by the distance d in Figure 2.3 (see
Section 2.4) should be taken into account at all times.
To move the machine supplied without a crate, any of
the solutions listed below can be used.
Fork-lift truck. Figure 2.3.
Fig. 2.3
Roller platforms positioned under the base-
plates
Caution!
The roller platforms must be fitted under the
strengthened area of the base-frame (Figure
2.4).
Never support machine at the ends of the
sides (Figure 2.5).
Fig. 2.4
Fig. 2.5
