GIRBAU PB32 Series User Manual

Technical data 40
Code no. 550038
Rev. no. 16/1018
4.3. CE certified models. Specific values for models with GAS heating
Consult the description of the burner in Section 1.2.
VERY IMPORTANT
NOTES RELATING TO POWER AND GAS DETAILS
Volumetric consumptions and massic consumption. Values calculated at 15ºC (59ºF); 1013 mbar (14.7
PSI).
4.3.1. Atmospheric burner. Heating data
ATMOSPHERIC BURNER. CE Models
MACHINE MODEL
Combustible gases circuit:
type B14 in accordance with EN1020
(Append. B)
UNITS
PB3215
PB3221
PB/PBP5119
PB/PBP5125
PB/PBP5132
Natural
G20
Supply pressure
mbar
20
20
20
20
20
(in.wc)
(8.03)
(8.03)
(8.03)
(8.03)
(8.03)
Volumetric consumption
m
3
/h
2.42
3.23
4.31
5.60
7.37
(cu.ft/h)
(85.5)
(114.1)
(152.2)
(197.8)
(260.3)
Nominal calorie cons.
with regard to H
i
kW
22.3
30.5
39.9
51.5
69.6
(BTU/h)
(76091)
(104070)
(136144)
(175725)
(237485)
Nominal calorie cons.
with regard to H
s
kW
24.8
33.9
44.3
57.2
77.3
(BTU/h)
(84501)
(115573)
(151192)
(195147)
(263733)
Injector diameter
mm
3.45
4.05
4.70
5.75
6.75
Natural
G25
Supply pressure
mbar
25
25
25
25
25
(in.wc)
(10.04)
(10.04)
(10.04)
(10.04)
(10.04)
Volumetric consumption
m
3
/h
2.67
3.85
4.82
6.16
8.68
(cu.ft/h)
(94.3)
(136.0)
(170.2)
(217.5)
(306.5)
Nominal calorie cons.
with regard to H
i
kW
22.3
30.5
39.9
51.5
69.6
(BTU/h)
(76091)
(104070)
(136144)
(175725)
(237485)
Nominal calorie cons.
with regard to H
s
kW
24.8
33.9
44.3
57.2
77.3
(BTU/h)
(84501)
(115573)
(151192)
(195147)
(263733)
Injector diameter
mm
3.60
4.20
4.90
6.00
7.10
Propane
G31
Supply pressure
mbar
37
37
37
37
37
(in.wc)
(14.85)
(14.85)
(14.85)
(14.85)
(14.85)
Massic consumption
kg/h
1.66
2.51
3.11
3.99
5.43
(lb/h)
(3.66)
(5.54)
(6.87)
(8.80)
(11.96)
Nominal calorie cons.
with regard to H
i
kW
22.0
32.1
41.1
52.6
69.4
(BTU/h)
(75067)
(109554)
140239)
(179479)
(236803)
Nominal calorie cons.
with regard to H
s
kW
23.9
34.9
44.7
57.2
75.4
(BTU/h)
(81593)
(119077)
(152430)
(195081)
(257388)
Injector diameter
mm
2.40
2.75
3.10
3.60
4.15
Propane
G31
Supply pressure
mbar
50
50
50
50
50
(in.wc)
(20.7)
(20.7)
(20.7)
(20.7)
(20.7)
Massic consumption
kg/h
1.66
2.51
3.11
3.99
5.43
(lb/h)
(3.66)
(5.54)
(6.87)
(8.80)
(11.96)
Nominal calorie cons.
with regard to H
i
kW
22.0
32.1
41.1
52.6
69.4
(BTU/h)
(75067)
(109554)
(140239)
(179479)
(236803)
Nominal calorie cons.
with regard to H
s
kW
23.9
34.9
44.7
57.2
75.4
(BTU/h)
(81593)
(119077)
(152430)
(195081)
(257388)
Injector diameter
mm
2.10
2.70
2.90
3.30
3.95
