4.5.2. Radiant burner. Heating data
RADIANT BURNER. ETL models
MACHINE MODEL
UNITS
X20075
X20100
X20125
Natural
Supply pressure
mbar
17.4
17.4
17.4
(in.wc)
(7.0)
(7.0)
(7.0)
Volumetric consumption
m
3
/h
5.06
6.48
7.96
(cu.ft/h)
(178.7)
(228.8)
(281.1)
Nominal calorie cons. with
regard to H
i
(Net)
kW
47.8
61.2
75.2
(BTU/h)
(163100)
(208823)
(256593)
Nominal calorie cons. with
regard to H
s
(Gross)
kW
53.1
68
83.5
(BTU/h)
(181185)
(231903)
(284914)
Injector diameter
mm
28.5
32
40,5 / 57*
Solenoid valve adjustm.
(See Figure 5.12).
mm
7
7
7
Propane
Supply pressure
mbar
27.4
27.4
27.4
(in.wc)
(11.0)
(11.0)
(11.0)
Massic consumption
kg/h
3.54
4.51
5.74
(lb/h)
(7.81)
(9.95)
(12.66)
Nominal calorie cons. with
regard to H
i
(Net)
kW
46.4
59.2
75.3
(BTU/h)
(158323)
(201999)
(256934)
Nominal calorie cons. with
regard to H
s
(Gross)
kW
50.5
64.3
81.8
(BTU/h)
(172313)
(219401)
(279270)
Injector diameter
mm
27.5
29
37 / 52*
Solenoid valve adjustm.
(See Figure 5.12).
mm
6
7
4.5
*Note: from machine No.2210031
4.5.3. Details of gas connection
INSTALLATION CHARACTERISTICS
ETL models
MACHINE MODEL
Types of gas
G20, G25, G31
Male thread
NPT
X13061
X13084
X20075
X20100
X20125
3/4 in
3/4 in
3/4 in
3/4 in
3/4 in
4.5.4. Electrical data: power and consumption
(Models with gas heating)
ELECTRICAL SPECIFICATIONS
ETL models
MACHINE MODEL
VOLTAGE
(50/60Hz)
X13061
X13084
X20075
X20100
X20125
Maximum electrical power
200…480
kW
0.7
0.7
1.01
1.01
1.01
Total nominal consumpt.
200…240
A
4.70
4.70
6.10
6.10
6.10
380…480
A
2.1
2.1
3.00
3.00
3.00
Note. This information should be supplemented with images and information from Section 4.8.
