GIRBAU PB32 Series User Manual

Technical data 38
Code no. 550038
Rev. no. 16/1018
4.2.2. Machines with electric heating
Nameplate:
Heating ........................... E
Voltage ........................... 200…240
Phases ............................ 3Ph
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 200…240
Phases ............................ 3Ph
Connection (number of wires):
3 + PE/GND
PB3215
X13061
Wire section
mm
2
16
AWG
4
Automatic External Switch
A
63
PB3221
X13084
Wire section
mm
2
25
AWG
2
Automatic External Switch
A
80
PB/PBP5119
X20075
Wire section
mm
2
50
AWG
0
Automatic External Switch
A
125
PB/PBP5125
X20100
Wire section
mm
2
70
AWG
000
Automatic External Switch
A
160
PB/PBP5132
X20125
Wire section
mm
2
95
AWG
0000
Automatic External Switch
A
200
Nameplate:
Heating ........................... E
Voltage ........................... 380…415
Phases ............................ 3Ph
CONNECTION DIAGRAM
Mains supply available (P):
Voltage ........................... 380…415
Phases ............................ 3Ph
Connection (number of wires):
3 + PE/GND
PB3215
Wire section
mm
2
6
AWG
8
Automatic External Switch
A
40
PB3221
Wire section
mm
2
10
AWG
6
Automatic External Switch
A
50
PB/PBP5119
Wire section
mm
2
16
AWG
4
Automatic External Switch
A
80
PB/PBP5125
Wire section
mm
2
25
AWG
2
Automatic External Switch
A
100
PB/PBP5132
Wire section
mm
2
50
AWG
0
Automatic External Switch
A
125
