GIRBAU PB32 Series User Manual

Technical data 34
Code no. 550038
Rev. no. 16/1018
4. TECHNICAL AND CONNECTION DATA FOR THE MACHINE
4.1. General technical details
CONCEPT
UNIT
MODELS
PB3215
X13061
PB3221
X13084
PB/PBP5119
X200075
PB/PBP5125
X20100
PB/PBP5132
X20125
Roll diameter
mm
(in)
325
(12.8)
325
(12.8)
510
(20.1)
510
(20.1)
510
(20.1)
Usable length of roll
mm
(in)
1540
(60.6)
2120
(83.5)
1900
(74.8)
2530
(99.6)
3165
(124.6)
Ironing surface
m
2
(sq.ft)
0.96
(10.3)
1.32
(14.2)
2.12
(22.8)
2.82
(30.4)
3.53
(38)
Heating
Gas
G
Yes
Yes
Yes
Yes
Yes
Steam
V
No
No
Yes
Yes
Yes
Electric
E
Yes
Yes
Yes
Yes
Yes
Evaporation capacity
(nominal heating
power)
G
l/h
(cu.ft/h)
15
(0.5)
20
(0.7)
30
(1.1)
40
(1.4)
60
(2.1)
E
l/h
(cu.ft/h)
15
(0.5)
20
(0.7)
30
(1.1)
40
(1.4)
50
(1.8)
V
l/h
(cu.ft/h)
- - - - -
- - - - -
42
(1.5)
56
(2.0)
70
(2.5)
Maximum speed.
Normal
speed
m/min
(ft/min)
5
(16)
5
(16)
9
(30)
9
(30)
9
(30)
High speed
m/min
(ft/min)
11
(36)
11
(36)
15
(49)
15
(49)
15
(49)
Roller motor power
capacity (1)
50Hz
kW
0.30
0.30
0.30
0.30
0.30
60 Hz
HP.
0.40
0.40
0.40
0.40
0.40
Extraction motor
power capacity (1)
50Hz
kW
0.30
0.30
0.55
0.55
0.55
60 Hz
HP.
0.40
0.40
0.74
0.74
0.74
Radiant burner power
capacity
120V; 60Hz
kW
- - - - -
- - - - -
0.068
0.068
0.068
230V;
50/60Hz
kW
- - - - -
- - - - -
0.055
0.055
0.055
Sound level
dB
<70
<70
<70
<70
<70
Protection index
IP
51
51
51
51
51
Vibrations
none
none
none
none
none
Folder
NO
NO
PBP5119
X200075F
PBP5125
X20100F
PBP5132
X20125
Note 1. The voltage of the roller and extraction motors is 200…240, 1Ph+N / 2PH regardless of the machine’s
supply voltage.
