Operating and use. Inteli Control 99
Code no. 550038
Rev. no. 16/1018
Programming the folding
This programming only appears on machines
with a folder incorporated.
Folding modes
1. Operation in manual mode
2. Operation in advanced manual mode
3. Operation in automatic mode
4. Folder halted
Press the ◄/► keys to select the desired
option.
See details below.
Operation in manual mode
The programmed length can be altered by
pressing the + / - keys.
The ironer control automatically determines the
number and length of the folds.
Programmable range:
cm. 60 – 400 (min-max)
in. 24 – 157 (min-max)
Operation in advanced manual mode
The programmed length can be altered by
pressing the + / - keys.
Programmable range:
cm. 60 – 400 (min-max)
in. 24 – 157 (min-max)
The ironer displays the number of possible folds
depending on the length of the article to be
folded.
Users must select the most appropriate option for
their requirements.
Number of folds
possible:
2, 4, 6, 8, 10, 12, 14.
Operation in automatic mode
The ironer control measures the length of each item and automatically determines the number
and length of the folds.
Folder halted
To restart the folder, select one of the above options or press the corresponding button on the
control panel.
See Section 7.5.4 for further information on using the folder.
