Component Identification 506
3A6748B 11
Component Identification 506
NOTE: All hoses sent with the unit are for
water-based material application only.
* See page14 for all applicators.
1 Pump Module
2 Hopper Frame
3Pump
4 Pump Outlet
5 Pressure Relief Valve
6 Module Securing Clamp
7 Power Cord
8 ON/OFF Switch
9 Display
10 Pressure Control Knob
11 Locking Pin
12 Hopper Plug
13 Scraper Tool
14 Whip Hose
15 Material Hose
16 T-Max Applicator
17 Inline Applicator
18 Tool Box
