Component Identification 6912
3A6748B 13
Component Identification 6912
NOTE: All hoses sent with the unit are for
water-based material application only.
* See page14 for all applicators.
1 Pump Module
2 Hopper Frame
3Pump
4 Pump Outlet
5 Pressure Relief Valve
6 Module Securing Clamp
7 Power Cord
8 Pump Mode Switch
9 ON/OFF Switch
10 Amp Switch
11 Display
12 Pressure Control Knob
13 Locking Pins
14 Hopper Plug
15 Signal / Air Hose
16 Scraper Tool
17 Material Hose
18 Whip Hose
19 Tool Box
20 Free Flow Applicator
21 STX Spray Gun
