Graco T-MAX 506 User Manual

Technical Specifications
84 3A6748B
Technical Specifications
T-Max 506
US Metric
Power requirements . . . . . . . . . . 100-120 Vac 220-240 Vac
50/60 Hz, 13A 50/60 Hz, 8A
Motor. . . . . . . . . . . . . . . . . . . . . . 1.2 HP 900 W
Maximum fluid working pressure 730 psi 5.0 MPa, 50 bar
Maximum air working pressire . . 250 psi 1.7 MPa, 17 bar
Generator required . . . . . . . . . . . 7 kW
Hopper capacity . . . . . . . . . . . . .
Maximum
20 gallons
76 liters
Operating 17 gallons 64 liters
Maximum delivery with texture
material. . . . . . . . . . . . . . . . . . . .
1.2 to 1.7 gpm 4,5 to 6,4 lpm
Fluid outlet size. . . . . . . . . . . . . . 1.0 in. (m) cam and groove
Dimensions
Length (with handle) . . . . . . . . . . 42 to 44 in. 107 cm to 112 cm
Width. . . . . . . . . . . . . . . . . . . . . . 23 in. 58 cm
Height . . . . . . . . . . . . . . . . . . . . . 46 in. 117 cm
Weight
Module only 88 lb 40 kg
Module & hopper . . . . . . . . . . . . 156 lb 71 kg
Noise (dBa)
Maximum sound pressure . . . . .
82.4
Maximum power level. . . . . . . . .
97.0
Sound pressure measured 3.28 feet (1 meter) from equipment.
Sound power measured per ISO-3744.
Wetted Parts
Buna-N, aluminum, brass, polyethylene, neoprene, stainless steel, chrome-plated carbon
steel, nickel-plated carbon steel, viton, nickel-plated iron, wool felt, tungsten carbide, PTFE
