Technical Specifications
3A6748B 85
T-Max 657
US Metric
Power requirements . . . . . . . . . . 100-120 Vac 220-240 Vac
50/60 Hz, 13A 50/60 Hz, 8A
Motor. . . . . . . . . . . . . . . . . . . . . . 1.2 HP 900 W
Maximum fluid working pressure. 940 psi 6.5 MPa, 17 bar
Maximum air working pressire . . 250 psi 1.7 MPa, 17 bar
Generator required . . . . . . . . . . . 7 kW
Dimensions
Maximum 28 gallons 106 liters
Operating 25 gallons 95 liters
Maximum delivery with texture
material . . . . . . . . . . . . . . . . . . . .
1.4 to 1.9 gpm 5,3 to 7,2 lpm
Fluid outlet size . . . . . . . . . . . . . . 1.0 in. (m) cam and groove
Dimensions
Length (with handle) . . . . . . . . . . 46 to 48 in. 117 cm to 122 cm
Width. . . . . . . . . . . . . . . . . . . . . . 23 in. 58 cm
Height . . . . . . . . . . . . . . . . . . . . . 46 in. 117 cm
Weight
Module only 91 lb 41 kg
Module & hopper. . . . . . . . . . . . . 160 lb 73 kg
Noise (dBa)
Maximum sound pressure. . . . . .
82.4
Maximum power level . . . . . . . . .
97.0
Sound pressure measured 3.28 feet (1 meter) from equipment.
Sound power measured per ISO-3744.
Wetted Parts
Buna-N, aluminum, brass, polyethylene, neoprene, stainless steel, chrome-plated carbon
steel, nickel-plated carbon steel, viton, nickel-plated iron, wool felt, tungsten carbide, PTFE
