Component Identification
14
3A6748B
Component Identification
Free Flow
Applicato
r (17Z128)
T-Max Applicator
(17Z054)
STX Spray Gun
(17Y910)
18m Remote
Switch (17Z
157)
30m Remote
Switch (17Z158)
13m Signal/Air
Hose (17Z14
4)
18m Signal/Air
Hose (17Z148
)
33m Signal/Air
Hose (17Z151
)
Inline Appli
cator
(17Y907)
13
15
Table of Contents
