Graco T-MAX 506 User Manual

Start Up - Air Assist
3A6748B 29
4. Prime pump.
a. Place material hose in hopper.
b. Turn ON/OFF Switch to ON.
c. Place Pump Mode Switch in down
position. Turn Pressure Control
Knob clockwise 1/4 turn.
d. Once a steady stream flows from
the material hose, run for an
additional 30 seconds.
e. Turn ON/OFF Switch to OFF.
ti11697a
