Note:
The GXP2200EXT is an additional accessory for the GXP2200 and is not included in the GXP2200 box.
To set up the GXP2200EXT with the GXP2200, please follow the steps below:
1. On the back of the GXP2200 and the GXP2200EXT, there are slots for connector plate. Attach the
connector plate between the slots for GXP2200 and the GXP2200EXT;
2. Apply the screws provided and securely tighten them in (See Figure 3: GXP2200 Back View with
GXP2200EXT);
3. Connect the GXP2200EXT to the GXP2200 via EXT port using the RJ11-RJ11 cable provided;
4. Install the phone stand on the GXP2200 and the GXP2200EXT;
5. Power up the GXP2200. The GXP2200EXT will show the booting up screen with version information
and connecting status;
6. After successfully booting up, the GXP2200EXT will stay in idle. Press and hold the Left button for 3 to
5 seconds to check the version information and status.
