Firmware Version 1.0.3.26 GXP2200 USER MANUAL Page 32 of 159
Conference. Press to conference call.
Note:
To capture a screenshot, press the MENU and SEARCH button at the same time. Then
the screenshot picture will be saved under File Manager->user_data->screenshot folder.
USING THE MESSAGE WAITING INDICATOR
The GXP2200 message waiting indicator LED is on the top right corner of the device. It could notify the
users with different messages and status of the phone. Please refer to the status description below. The
priority for the LED indicator is from high to low in the following table.
Table 7: GXP2200 MWI LED Status
Missed call (s), New voicemail (s), New SIP Message (s)
High memory usage, Maximum number of messages,
Maximum contact storage
Phone is on but the screen is off
MANAGING STATUS BAR
The GXP2200 status bar is located on the top of the screen. Touch the bar and slowly drag it down to
display the full status list.
