40 Transmitter description - Telemetry data display
GPS
RX–S QUA: 100%
RX–S ST : 100%
TX–dBm: 33dBm
RX–dBm: 33dBm
RX–SPG.:4.8 TMP
V–PACK: 10ms
CH OUTPUT TYPE:ONCE
RECEIVER
GENERAL
ELECT. AIR
VARIO
GPS
N
RXSQ 0
DIS 0m
ALT 0m
0.0m/1s
0m/3s
0m/10s
N 0°00.0000
O 0°00.0000
W
E
S
Kmh
0
If attached to the receiver, this display will depict the
data from a GPS module with integrated Vario, Order
No. 33600.
Aside from the model's current position and speed,
the center section of this screen will also display
current altitude with respect to the starting location
as well as the model's current ascent/decent rate in
m/1 s, m/3 s and m/10 s, current reception quality
and the model's distance from its starting location.
The displayed items are as follows:
Value Explanation
W / N / O / S west / north / east / south
Kmh speed
RXSQ return channel signal strength
DIS distance
ALT current altitude with respect to starting
m/1 s m/1 s ascent/decent rate
m/3 s m/3 s ascent/decent rate
m/10 s m/10 s ascent/decent rate
GPS
N
W
O
S
Kmh
0
km/h
DIS
m
m/s
ALT
m
0
0
0.0
0
If attached to the receiver, this display will depict the
data from a GPS module with integrated Vario, Order
No. 33600.
The displayed items are as follows:
Value Explanation
km/h speed
DIS horizontal distance in m
m/s ascent/decent rate in m/s
ALT altitude relative to starting location in m
Vario
0.0
0
m
m
s
If attached, this display will depict the altitude (in m)
relative to location, starting location as well as the
current rate of ascent/descent (in m/s) from data
originating from the Vario integrated into the
GPS-/Vario module (order no. 33600).
