39
Transmitter description - Telemetry data display
L or H cell voltage of cells 1 … max. 14
L = balancer connection 1
H = balancer connection 2
AKKU 1
0.0V
0.0A
0mAh
This display depicts current voltage, current current
draw and, if attached, the expended capacity of
"Batt 1" connected to the Electric-Air module (order
no. 33620).
SENSOR 1
0.0V
0°C
SENSOR 1
If attached, this display depicts currently measured
voltage and temperature from a temperature/voltage
sensor (order no. 33612 or 33613) connected
to "T(EMP)1" of the Electric-Air module (order
no. 33620).
SENSOR 2
0.0V
0°C
SENSOR 2
If attached, this display depicts currently measured
voltage and temperature from a temperature/voltage
sensor (order no. 33612 or 33613) connected
to "T(EMP)2" of the Electric-Air module (order
no. 33620).
Vario
0.0
0
m
m
s
If attached, this display will depict the altitude
(in m) relative to location, starting location as well
as the current rate of ascent/descent (in m/s) data
originating from a Vario integrated into a Electric-
Air module (order no. 33620).
VARIO
RX–S QUA: 100%
RX–S ST : 100%
TX–dBm: 33dBm
RX–dBm: 33dBm
RX–SPG.:4.8 TMP
V–PACK: 10ms
CH OUTPUT TYPE:ONCE
RECEIVER
GENERAL
ELECT. AIR
VARIO
GPS
RXSQ
0
MAX
0m
MIN
0m
ALT
0
H
L
m/1s
0.0
m/3s
0.0
m/10s
0.0
If attached to the receiver, this display will depict the
data acquired by a Vario module, order no. 33601.
The displayed items are as follows:
Value Explanation
ALT current altitude
RXSQ Signal strength of the signal received
by the receiver in %, see page 230.
MAX the preset maximum altitude limit
relative to starting location at which,
when exceeded, will cause an audible
warning to be sounded
MIN the preset minimum altitude limit
relative to the starting location at which,
when underrun, will cause an audible
warning to be sounded
m/1 s m/1 s ascent/decent rate
m/3 s m/3 s ascent/decent rate
m/10 s m/10 s ascent/decent rate
Vario
0.0
0
m
m
s
If attached, this display will depict altitude relative
to location or starting location (in m) as well as the
current rate of ascent/decent (in m/s) from data
acquired by a Vario module (order no. 33601).
