• REVERSE
It is used to reverse the operation of an individual servo.
Touch “SET” icon to activate “OFF” in red and touch INC and DEC buttons to switch to
“ON”. Touch “SET” icon again to deactivate the value and touch INC buttons to move the
cursor to “CENTER”.
• CENTER
It is used to set the “center position” of servo.
Touch “SET” icon to activate the value in red. Move and hold the throttle stick to the desired
position for the servo center and touch “SET” icon then that position is assigned to the servo
center and the relevant value is displayed. Touch INC button to move the cursor to “TRIM”
• TRIM
It is used to set the servo’s “Trim position”.
Touch “SET” icon then the values of CENTER and TRIM are activated in red. Adjust TRIM values
with INC and DEC buttons and touch “SET” icon again to deactivate the value. Touch INC button to
move the cursor to “LIMIT -”
NOTICE: When TRIM value is adjusted, the default value of CENTER, 1500usec, is automatically
set and the trim setup value is added to 1500usec.
Touch
Touch
Touch
Touch
Touch
Touch
Touch
Touch
Touch
55
