GRIT Lock - GRIT Switch; Installation

Red/Green LED status indicator light
Illuminating LED rocker button
Power jack
Low-voltage jack (receives power)
Charging dock with 1-1/4'' mounting screws
Mount charging dock in a convenient location with supplied screws.
To power the charging dock use either the low-voltage jack or the 120v power adapter.
Place the Switch on the charging dock to charge.
GRIT Switch
The Switch device includes:
1.
2.
3.
4.
5.
(and velcro, if preferred)
Installation
1.
2.
3.
*Note: The battery will last 1-2 weeks between charges.
2
1
3
The GRIT Switch is a wireless trigger that can be configured exactly the same as other
triggers, except instead of having the tool activate the collector, the toggle switch does.
These are often used for a shop's floor sweep or for a work station that has rotating tools
or wood lathes.
1
2
3
4
5
TRIGGERS
63
Triggers
Switch
