Bin debris iR sensor
Removable low-voltage terminal (receives power from Collector device)
Removable low-voltage jack (supplies power to Strobe Light only)
Strobe Light
Removable low-voltage terminal (receives power)
10ft 18/2 solid copper thermostat wire
Power drill with step bit
Flathead screwdriver (provided)
Wire stripper
Dust Bin Sensor
The Dust Bin Sensor device includes:
1.
2.
3.
4.
5.
6.
Installation
The instructions to install your Dust Bin Sensor are listed below. You will need the
following tools to complete installation:
The GRIT Dust Bin Sensor detects the debris level in the dust bin and alerts you with a red
strobe light that it needs to be emptied. For maximum visibility, multiple strobe lights can
be daisy-chained.
