GRIT Lock - 120 V and 220 V Collectors; Installation

Removable low-voltage terminal (supplies power)
Red/Green LED Lock status indicator light
Standard 120v plug/socket
220v plug fits in any standard 15a or 20a outlet
220v socket accepts any 15a or 20a tool plug
Plug your collector into the GRIT Collector device.
Plug GRIT Collector device into the wall.
Turn on your collector's manual switch (not pictured).
120v and 220v Collectors
The 120v and 220v Collector devices include:
1.
2.
3.
4.
5.
Installation
1.
2.
3.
1
1
2
2
3
4
5
1
2
COLLECTORS
The GRIT Collector device controls dust collectors. It can be linked to triggers and will turn
on/off automatically.
65
Collectors
Installation
