Manually slide the gate's tab so
that the gate is approximately half
open.
While keeping the gate's tab half
open, push the Arm down onto the
servo.
Secure with the M3 x 14mm screw.
Then finish calibrating the open
and closed positions per the
'Calibration' instructions.
87
Gate Control
Installation
