4.6.1 Browsing Zone Definition
The zone information defined by the definition software can be browsed on the LCD of
the FACP following the steps below.
Step 1: Pressing SYSTEM to enter system setting menu, as in Fig. 4-12.
Fig. 4-12
Step 2: Choosing ”5. Zone browse” can browse the zone definition as shown in
Fig.4-13.
Fig. 4-13
Notes:
 Zone 0001 1floor// Zone number and descriptions.
Ver V4.05
f
System setup
1． Modify password
2． Communicate setup
3． Working state setup
4． Fire display mode
5． Zone browse
6． C&E browse
7. Monitoring Device
Ver V4.05
f
Display the Zone Name
Zone 0001 1floor
Zone 0002 2floor
Zone 0003 3floor
Zone 0004 4floor
Zone 0005 5floor
Zone 0006 6floor
Zone 0007 7floor
Zone 0008 8floor
