GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 42
Chapter 6 Description of System Operation
6.1 Keypad
6.1.1 Functions
Most of the keys have double functions. Upper mark is a character and lower mark is
command function that is only activated in monitoring state. Most function keys are
controlled by password. The characters are only active after entering the menu.
6.1.2 Common Method of Data Input
There is a highlighted area indicating the current position and range of data input. Press
a character key, the highlight and original characters disappear and input from that
character. Move the highlight tab to any position for modification by pressing
△
＝
or
＝
▽
.
Press TAB, the edited text is stored and the highlight moves to the next position and
returns to the first after the last position. Wherever the cursor is, Press ENTER key, all
the input data will be saved; press ESC to exit present editing state without saving.
6.1.3 Method of Browsing Information
Entering browsing state, press
△
＝
and
＝
▽
to scroll for information.
Press ENTER, the top piece of information becomes highlighted and the system enters
information selection state. Press TAB and exit highlight state.
In selecting state, press
△
＝
and
＝
▽
to select highlight tab.
Pressing ENTER can print the information or display details of the information. Pressing
ESC will exit to the previous menu or normal operation screen.
6.1.4 Keypad Unlock and Lock
The FACP is defaulted as key-locked on start-up. A password needs to be input if you
operate any of the function keys (except for SELF TEST, MUTE, LOG, VIEW FIRE,
VIEW FAULT, VIEW DISABLE and VIEW PLANT) (refer to Fig. 6-1). Input correct
password and press ENTER to continue operation. After one minute without operation,
the keys are automatically locked.
