GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 30
Pressing “3” in Fig. 3-11 can view the spaces for C&Es, as in Fig. 4-18.
Fig. 4-18
4.7 Field Devices Commission
After connection of cables, definition and download of device and C&E equations,
you can power up the FACP and start commission. The following steps are for
reference.
1. Enter commission state according to Section 4.5.
2. Check whether the loop devices registered are the same as real connection. If
most of devices are found missing, check the power supply and loop isolators
first, then come to individual device. Press SELF TEST key to check field
device registration.
3. Check whether registration of repeater panels is the same as the actual. If
there is any problem, check the communication cable A and B and 24V power
supply.
4. Label the ZCP at the correct places.
5. Carry out detector alarm test and repeater panel transmitting test.
6. Check device definition and execute C and E automatic linkage test.
7. Connect important devices (such as gas extinguishing control panel) and train
the operators.
Ver V4.05
