GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 31
Chapter 5 Display and Disposal of System Information
GST5000 can be started after mounting according to Chapter 4.
5.1 Normal Information
Turn on the external power switch, and main and standby power switch on the FACP,
the control panel executes self-test and enters monitoring state. The system displays
properly if it is in normal state, or the system displays improperly.
The normal display is shown in Fig. 5-1, which means the system is in working state.
Then only POWER HEALTHY LED illuminates.
Fig. 5-1
5.2 Information of Fire Alarm
5.2.1 Fire Alarm Screen
FIRE LED is illuminates when there is fire alarm signal. Speaker of the control panel
sounds (fire truck sound), and corresponding fire LED on the ZCP is also lit. There are
two options for fire display, by zone and by device. In zone mode, only the 1
st
alarm in
the same zone is displayed. All alarms will be displayed in device mode. Device mode is
usually used for commission.
① Zone mode fire information shows in Fig. 5-2.
