 1 floor cookroom// Zone description ＋ device description
 №017 Zone 002-017 Fix Temp// Message number, user code (zone number +
device number), device type
 1 floor bathroom// Zone description ＋ device description
 №032 Zone 003-032 Optical// Message number, user code (zone number +
device number), device type
 1 floor corridor // Zone description ＋ device description
 №214 Zone 003-214 Fresh Air// Message number, user code (zone number +
device number), device type
 1 floor toilet// Zone description ＋ device description
In device browsing state, pressing
△
＝
and
＝
▽
can turn pages. In device selection state,
pressing
△
＝
and
＝
▽
can change the selected device.
4.6.3 Viewing C&E
The C&E equations defined by the definition software can be browsed on the LCD of the
FACP following the steps below.
Step 1: Pressing SYSTEM will enter system setting menu as shown in Fig. 4-12.
Step 2: Choosing “6. C&E browser”, the screen for browsing C&E will show. Pressing
“1” can display the C&E for gas extinguishing devices, and pressing “2” will display
ordinary C&Es (Fig. 4-17). Pressing ENTER, the screen prompts “Please Input the
number”, and you can view the C&E by entering its number.
