GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 38
5.5 Manual Start and Stop of Loop Devices
When fire alarm is confirmed, you can manually start extinguishing equipment in short
time.
5.5.1 START/STOP Operation through Keypad
1. Starting a loop device
Pressing START can start a loop device, and the screen is shown in Fig. 5-8.
Fig. 5-8
The basic steps are as follows:
Step One: Input the user code of the device to start.
Step Two: Pressing TAB, device type is highlighted.
Step Three: Input the device type referring to “Appendix 2 Device Type List”.
Step Four: Pressing ENTER, the control panel gives start command.
After the device is started, PLANT CONTROL LED and action indicator on the ZCP will
be lit.
2. Stopping a loop device
Pressing STOP can stop a loop device. The screen is shown in Fig. 5-9.
Ver V4.05f
start> 001zone 016Num 03 -Undefine
