GST GST5000 - Chapter 5 Display and Disposal of System Information

GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 26

△
＝
and
＝
▽
can be used for turning pages.
4.6.2 Browsing Device Information
The device information defined by the definition software can be browsed on the LCD of
the FACP following the steps below.
Step 1: Press BROWSE will enter the screen shown in Fig. 4-14. All system
configurations will be displayed.
Fig. 4-14
Step 2: Check loop configuration.
Pressing any key in the screen shown in Fig. 4-14 will enter the screen displaying loop
configuration, with the top line highlighted. Pressing TAB, the highlight will disappear
and the FACP will check the loop. Pressing
△
＝
and
＝
▽
will move the highlight bar on
different loops (Fig. 4-15).
Browse Register info
System Configuration
Total Loops 004
Devices 013
Repeaters 0000
Access 000
Color CRT Installed
