GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 43
Fig. 6-1
6.2 User Operation Instruction
6.2.1 Changing time display
The clock is usually displayed in hour and minute (time mode) by the digitron on the
panel. In normal monitoring state, pressing TAB, month and day (date mode) are
displayed. Press TAB again or after a minute, time mode is displayed again.
6.2.2 Browsing history records
Pressing LOG, the system enters history information screen. Each piece of information
includes the event time, 6-digit user number, event type and brief description of the
event.
6-digit user number: If the event refers to an addressable device, the first 3 digits show
zone number, the following 3 digits show the user code in this zone. If the information is
about loop or bus, this number will be the loop or bus number.
Device type: It shows the device type for device information or the operation type for
system operation.
Event description: Provides a brief description on the events, such as fire, start, action,
fault, stop, disable, enable, action reset, set and operation etc.
Press ENTER key to highlight an information, press
△
＝
and
＝
▽
to scroll up and down.
Press ENTER again to print the highlighted information, as shown in Fig. 6-2.
Ver V4.05f
Enter password*****
