GST GST5000 - Rack Type GST5000 FACP

GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 4
CLOCK
GST5000 Intelligent Fire Alarm Control Panel
×
Display and
operation area
LCD
Printer
Zone indication and
manual interventional
panel
Fireman's
control panel
1
7
0
m
m
500mm
700mm
Fig. 2-1
2.6.2 Rack type GST5000 FACP
Dimension (L × W × H): 580mm×520mm×1715mm
