GST5000 Intelligent Fire Alarm Control Panel
Installation and Operation Manual (Generic Part)
The Intelligent Solution
Page 3
Recommended Wiring: GST FireCable ® 2E/1.0 2core and Earth 1mm
2
CSA
2.5 Output Loop Parameters
Recommended Wiring: GST FireCable ® 2E/1.0 2core and Earth 1mm
2
CSA
(1) FIRE ALARM OUTPUT (+, -)
Output Voltage: 21VDC～27VDC
Output Current: 0.5A
Terminal Resistor: 4.7KΩ
(2) F.P.E OUTPUT (+, -)
Output Voltage: 21VDC～27VDC
Output Current: 0.5A
Terminal Resistor: 4.7KΩ
(3) SOUNDER CIRCUIT OUTPUT (+, -)
Output Voltage: 21VDC～27VDC
Output Current: 0.5A
Terminal Resistor: 4.7KΩ
(4) FAULT OUTPUT (NC, COM, NO)
Contact Capacity: 24VDC @1.0A
In fault state, NC and COM open, NO and COM close.
2.6 Dimension
2.6.1 Wall-mounted GST5000W FACP
Dimension (L × W × H): 500mm×170mm×700mm
