3.3.1.2 Dimensions and connections 402B
The FlexxPump 402B weighs approx. 1500g and has the following dimensions:
D003485
94
110
96
107
35,3
196
A
Fig.3-4 Dimensions and connections 402B
A Hydraulic outputs
Connections
Hydraulic:
• Two connections for hydraulic tubes with a diameter of 6/3mm
Operating voltage
The operating voltage is 3VDC.
