NOTE
Lubricating film missing
A missing lubricating film on guideways and racks leads to damage to the
product. This results in operational failure.
• Ensure that there is always a lubricating film on guideways and racks during
operation
• Perform the described tasks at the specified times
• Perform lubrication work at the latest when the first signs of tribocorro-
sion (reddish discoloration of the track) are visible
• Adjust lubrication interval if necessary
7.3.5 Replacing the FlexxPump
7.3.5.1 Disassembling the FlexxPump
Disassemble the FlexxPump as follows:
1 Switch off the system and secure it with a padlock against being switched
on again
2 Remove connecting cable
3 Disconnect the hydraulic lines from the hydraulic outputs
4 Loosen the screws
5 Remove FlexxPump
The FlexxPump has been removed.
Maintenance
OPERATING MANUAL Automatic lubrication system
FlexxPump 402 / 402B
90071992656444683_v9.0_EN-US
90
