5.3.5 Actuate
5.3.5.1 FlexxPump 402
The output signal on PIN 4 is High (20...30V) during normal operation.
Malfunctions are signaled on PIN 4 as follows:
Malfunction Signal Cause Measure
The type of er-
ror can only be
read on the dis-
play of the
FlexxPump.
Low
(0V)
Various causes Ü2106
Table5-2 Malfunction FlexxPump 402
