5.3 Installing
5.3.1 Prerequisites
Dispose of the packaging in accordance with the local waste regulations.
Ü2117
Checking the deliv-
ery
Check the scope of delivers based on the shipping papers. Check the product
for damage. Report transport damage immediately.
Interfaces
Check if the required interfaes are available and ready for use. Order informa-
tion on the connecting cable ÜChapter11,2121.
The following interfaces are needed:
Interface 402 402B
Lubricating pinion for
gear teeth and
Lubricating element for
guideway rail
X X
Connecting cable
M12x1, 4-pole
with the corresponding
length
X
PLC
Table5-1 Interfaces
Assembly site
The following prerequisites apply to the installation site:
• Level surface that is at least 107mm long and 45mm wide
• Sufficiently rigid
• In order to minimize condensation, the device should not be subjected to
direct sunlight and/or radiation heat
Commissioning
