4 Design, function
4.1 Design
The product consists of the following components:
• FlexxPump
• Splitters or Y-segments
• Hydraulic hoses
• Connecting cable, if necessary
More detailed information Ü248
D003515
A
B
C
E D
Fig.4-1 Design of FlexxPump lubrication system
A FlexxPump D Y-segment (combines lubricants)
B Connecting cable E Splitter (separates lubricants)
C Hydraulic hoses
