4.2.3 Splitter
4.2.3.1 Function
The quantity of lubricant at the input is distributed evenly between the out-
puts. The splitter only works in the direction of the arrow.
Lubrication quantity
½ lubrication quantity
½ lubrication quantity
Fig.4-6 Function: Splitter, 2-fold
